Develivery time:30-45 days
Model: IBR686
Payment:40% T/T deposit,60% balance before shipping
Voltage:380V 50HZ 3Phase or based on customer’s need.
WhatsApp:+86 188 3070 9860
The IBR roll forming machine is designed for producing high-quality IBR roofing sheets widely used in industrial buildings, warehouses, factories, commercial buildings, and residential roofing systems. The machine can process different metal materials such as PPGI, galvanized steel, and aluminum coils.
Our IBR roofing sheet roll forming machine adopts advanced roll forming technology to ensure stable performance, precise profile shaping, and high production efficiency. With over 30 years of manufacturing experience, we provide reliable and customized roofing sheet machines for customers worldwide.
The machine can produce 15–25 meters per minute, ensuring high output for large roofing sheet production.
The main frame is made of high-strength steel with precision machining, ensuring long-term stability and durability.
Multiple roller stations guarantee accurate shaping of the IBR roofing sheet profile with smooth surface and consistent dimensions.
The machine is equipped with a PLC control system and touch screen, allowing easy operation and automatic production.
We can customize the IBR roof sheet forming machine according to your profile drawing, material thickness, and production requirements.
| No. | ibr roll forming machine | |
| 1 | Suitable to process | Color alu-zinc steel coil |
| 2 | Roller | 18Rows |
| 3 | Dimensions | 9.0*1.7*1.8m |
| 4 | Motor Power | 5.5Kw |
| 5 | Pump Station Motor | 4Kw.Lichao Brand |
| 6 | Thickness of the plate | 0.3-0.8mm |
| 7 | Productivity | 10-15m/min |
| 8 | Material of the cutting blade | Cr12,Quenched treatment 58℃-60℃ |
| 9 | Diameter of the roller | Φ70mm |
| 10 | Weight | About 4800kgs |
| 11 | Main structure of the machine | 350H beams |
| 12 | Processing precision | Within 1.0mm |
| 13 | Side panel of machine | 16mm |
| 14 | Chain Wheel and Cycle Chain | 1 Inch |
| 15 | Voltage | 380V 50Hz 3phases or as customer’s need |
| 16 | Control system | PLC control (Delta) |
| 17 | Frequency system | Delta |
| 18 | Drive mode | Motor driver |
| 19 | Touch screen | Delta |
| 20 | Rolling materials | 45# forging steel with chromium plate |
| 21 | Length Tolerance | ±2mm |
The sheets produced by the IBR roll forming machine are widely used in:
1. Industrial factory buildings
2. Warehouses
3. Steel structure buildings
4. Residential roofing systems
5. Commercial buildings
6. Agricultural buildings
IBR roofing sheets are popular because of their high strength, good drainage performance, and attractive appearance.
✔ 30 years of roll forming machine manufacturing experience
✔ High-precision rollers and stable forming system
✔ Custom machine solutions for different markets
✔ Professional installation and technical support
✔ Competitive factory direct price
We have exported our IBR sheet making machines to many countries in Africa, South America, the Middle East, and Southeast Asia.
The machine can process PPGI, galvanized steel, aluminum, and other coated metal coils.
Yes. We can customize the machine according to your IBR profile drawing, sheet thickness, and production capacity.
The standard production speed is 15–25 meters per minute, depending on material thickness and machine configuration.
Yes. We can provide installation guidance, online support, or engineer service if required.
Xinnuo Machinery Co., Ltd., established in 1995, is a subsidiary of Hebei Xinnuo Roll Forming Machine Co., Ltd., previously known as Botou Huayu Roll Forming Machine Factory. We focus on the design, manufacturing, and sales of cold-formed machinery, offering a broad range of high-performance equipment.
Our star product, the sandwich panel production line, is one of our most popular machines and has been exported to countries across the globe. Renowned for its high efficiency and versatility, this machine is key in the production of insulated panels used in various industries. Our commitment to innovation is reflected in the over ten patents we hold, and our recognition as a National High-Tech Enterprise further solidifies our reputation as an industry leader.
