Develivery time:30-45 days
Model: IBR686
Payment:40% T/T deposit,60% balance before shipping
Voltage:380V 50HZ 3Phase or based on customer’s need.
WhatsApp:+86 188 3070 9860
| No. | ibr sheet making machine price | |
| 1 | Suitable to process | Color alu-zinc steel coil |
| 2 | Roller | Up Layer :13Rows（762） |
| Down Layer:18Rows(686） | ||
| 3 | Dimensions | 9.0*1.7*1.8m |
| 4 | Motor Power | 5.5Kw |
| 5 | Pump Station Motor | 4Kw.Lichao Brand |
| 6 | Thickness of the plate | 0.3-0.8mm |
| 7 | Productivity | 10-15m/min |
| 8 | Material of the cutting blade | Cr12,Quenched treatment 58℃-60℃ |
| 9 | Diameter of the roller | Φ70mm |
| 10 | Weight | About 6800kgs |
| 11 | Main structure of the machine | 350H beams |
| 12 | Processing precision | Within 1.0mm |
| 13 | Side panel of machine | 16mm |
| 14 | Chain Wheel and Cycle Chain | 1 Inch |
| 15 | Voltage | 380V 50Hz 3phases or as customer’s need |
| 16 | Control system | PLC control (Delta) |
| 17 | Frequency system | Delta |
| 18 | Drive mode | Motor driver |
| 19 | Touch screen | Delta |
| 20 | Rolling materials | 45# forging steel with chromium plate |
| 21 | Length Tolerance | ±2mm |
The IBR sheet making machine price depends on the machine structure, profile combination, and production requirements. This solution features a double layer roll forming machine designed to produce IBR 686 and corrugated 762 roof sheet profiles on one production line, providing excellent flexibility and cost efficiency.
The double layer design allows two different roofing profiles to be produced using a single machine, reducing initial investment and saving workshop space. It is an ideal choice for manufacturers who serve multiple roofing markets with limited factory area.
The IBR 686 roof sheet profile is widely used in industrial and commercial buildings, offering high strength, good load-bearing performance, and reliable installation. The corrugated 762 roof sheet profile is commonly applied in residential and light industrial roofing, providing good drainage performance and easy installation.
With stable forming accuracy, durable machine structure, and flexible configuration options, the final IBR sheet making machine price is confirmed according to material thickness range, production speed, cutting system, and local market requirements. This double layer solution delivers an excellent cost-performance ratio for long-term roofing sheet production.
